SIEMENS 6ES7332-5HD01-0AB0 Analog Output Module PLC

SIMATIC S7-300 series

Number of Outputs: 4 analog outputs

Output Signal Voltage Ranges: 0 to 10 V, 1 to 5 V, -10 to +10 V

Output Signal Current Ranges: 0 to 20 mA, -20 to +20 mA, 4 to 20 mA

Resolution: 12-bit for 0 to 10 V and 0 to 20 mA ranges​

11-bit plus sign for ±10 V, ±20 mA, 4 to 20 mA, and 1 to 5 V ranges

Conversion Time: 0.8 milliseconds per channel

Power Supply: Load Voltage (L+): 24 V DC​

Current Consumption: Up to 240 mA from L+ (without load), up to 60 mA from backplane bus

Power Loss: Approximately 3W

Connection Type: Requires a 20-pin front connector (not included)
